ifm Electronic PL2058 Frontbündiger Drucktransmitter

Product characteristics

• Number of inputs and outputs: Number of analogue outputs: 1
• Measuring range: -0.0125...0.25 bar, -12.5...250 mbar
• Process connection: threaded connection Aseptoflex external thread Aseptoflex

Application

• Special feature: Gold-plated contacts
• Application: flush mountable for the food and beverage industry
• Media: viscous media and liquids with suspended particles; liquids and gases
• Medium temperature [°C]: -25...80
• Min. bursting pressure [mbar]: 30000
• Pressure rating [mbar]: 6000
• Type of pressure: relative pressure
• No dead space: yes

Electrical data

• Operating voltage [V]: 14...30 DC
• Min. insulation resistance [MΩ]: 100; (500 V DC)
• Protection class: III
• Reverse polarity protection: yes
• Measuring principle: hydrostatic

Inputs / outputs

• Number of inputs and outputs: Number of analogue outputs: 1

Outputs

• Total number of outputs: 1
• Output signal: analogue signal
• Number of analogue outputs: 1
• Analogue current output [mA]: 4...20
• Max. load [Ω]: 550; (Ub = 24 V; (Ub - 13 V) / 20 mA)
• Overload protection: yes

Measuring/setting range

• Measuring range: -0.0125...0.25 bar, -12.5...250 mbar
• Analogue start point [mbar]: -12.5...100
• Analogue end point [mbar]: 50...250
• In steps of [mbar]: 0.5
• Factory setting: , ASP = 0.0 mbar, AEP = 250.0 mbar

Accuracy / deviations

• Repeatability [% of the span]: < ± 0,1; (with temperature fluctuations < 10 K; Turn down 1:1)
• Characteristics deviation [% of the span]: < ± 0,6; (Turn down 1:1 , linearity, incl. hysteresis and repeatability , limit value setting to DIN EN IEC 62828-1)
• Linearity deviation [% of the span]: < ± 0,5; (Turn down 1:1)
• Hysteresis deviation [% o
