ifm Electronic PG2450 Drucksensor mit analoger Anzeige

Product characteristics

• Number of inputs and outputs: Number of digital outputs: 1; Number of analogue outputs: 1
• Measuring range: 0...400 bar, 0...5800 psi
• Process connection: threaded connection G 1/2 external thread

Application

• Special feature: Gold-plated contacts
• Application: for industrial applications
• Media: liquids and gases
• Conditionally suitable for: use in gases at pressures > 25 bar only on request
• Medium temperature [°C]: -25...80
• Min. bursting pressure: 1200 bar, 17400 psi
• Pressure rating: 800 bar, 11600 psi
• Type of pressure: relative pressure

Electrical data

• Operating voltage [V]: 18...32 DC
• Current consumption [mA]: < 70; (24 V)
• Min. insulation resistance [MΩ]: 100; (500 V DC)
• Protection class: III
• Reverse polarity protection: yes
• Power-on delay time [s]: 6
• Integrated watchdog: yes

Inputs / outputs

• Number of inputs and outputs: Number of digital outputs: 1; Number of analogue outputs: 1

Outputs

• Total number of outputs: 2
• Output signal: switching signal; analogue signal; (configurable)
• Electrical design: PNP/NPN
• Number of digital outputs: 1
• Output function: normally open / normally closed; (parameterisable)
• Max. voltage drop switching output DC [V]: 2
• Permanent current rating of switching output DC [mA]: 250
• Switching frequency DC [Hz]: 75
• Number of analogue outputs: 1
• Analogue current output [mA]: 4...20, invertible; (scalable)
• Max. load [Ω]: (Ub - 10 V) / 20 mA
• Short-circuit protection: yes
• Type of short-circuit protection: pulsed
• Overload protection: yes

Measuring/setting range

• Measuring range: 0...400 bar, 0...5800 psi
• Set point SP: 2...600 bar, 30...8700 psi
• Reset point rP:
