ifm Electronic OGH202 Reflexlichttaster mit Hintergrundausblendung

Product characteristics

• Type of light: red light
• Housing: threaded type

Application

• Special feature: Background suppression
• Function principle: Diffuse reflection sensor

Electrical data

• Operating voltage [V]: 10...36 DC
• Current consumption [mA]: 25
• Protection class: II
• Reverse polarity protection: yes
• Type of light: red light
• Wave length [nm]: 624

Outputs

• Electrical design: PNP
• Output function: light-on mode
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 200
• Switching frequency DC [Hz]: 1000
• Short-circuit protection: yes
• Type of short-circuit protection: pulsed
• Overload protection: yes

Detection zone

• Range [mm]: < 100; (white paper 200 x 200 mm 90% remission)
• Range adjustable: no
• Max. light spot diameter [mm]: 9
• Light spot dimensions refer to: Range
• Background suppression available: yes

Operating conditions

• Ambient temperature [°C]: -25...60
• Protection: IP 67

Tests / approvals

• EMC: EN 60947-5-2,
• MTTF [years]: 372

Mechanical data

• Weight [g]: 52.6
• Housing: threaded type
• Dimensions [mm]: M18 x 1 / L = 72
• Thread designation: M18 x 1
• Materials: housing: stainless steel; PA; Sealing: FKM
• Lens material: glass

Displays / operating elements

• Display: switching status, 1 x LED, yellow

Accessories

• Items supplied: lock nuts: 2

Remarks

• Pack quantity: 1 pcs.

Electrical connection

• Connection: Connector: 1 x M12; coding: A

OGH202-01 — 13.04.2023 —
