ifm Electronic OG0032 Reflexlichtschranke

Product characteristics

• Type of light: red light
• Housing: threaded type

Application

• Special feature: polarisation filter
• Function principle: Retro-reflective sensor

Electrical data

• Frequency AC [Hz]: 47...63
• Operating voltage [V]: 20...250 AC/DC
• Protection class: II
• Reverse polarity protection: no
• Type of light: red light
• Wave length [nm]: 660

Outputs

• Output function: dark-on mode
• Max. voltage drop switching output DC [V]: 8
• Max. voltage drop switching output AC [V]: 8
• Minimum load current [mA]: 5
• Max. leakage current [mA]: 1.7
• Permanent current rating of switching output AC [mA]: 90; (180 (...40 °C))
• Permanent current rating of switching output DC [mA]: 90; (180 (...40 °C))
• Short-time current rating of switching output [mA]: 600; (20 ms / 0,5 Hz)
• Switching frequency AC [Hz]: 25
• Switching frequency DC [Hz]: 25
• Short-circuit proof: no
• Overload protection: no

Detection zone

• Range referred to prismatic reflector [m]: 3; (Prismatic reflector Ø 80 E20005)
• Range adjustable: yes
• Max. light spot diameter [mm]: 262
• Light spot dimensions refer to: at maximum range
• Polarisation filter available: yes

Operating conditions

• Ambient temperature [°C]: -25...80
• Protection: IP 67

Tests / approvals

• EMC: EN 60947-5-2,
, EN 55011, class B
• MTTF [years]: 339

Mechanical data

• Weight [g]: 122.6
• Housing: threaded type
• Dimensions [mm]: M18 x 1 / L = 78.5
• Thread designation: M18 x 1
• Materials: PBT
• Lens material: PMMA

Displays / operating elements

• Display: switching status, 1 x LED, red
, function, 1 x LED, red flashing
