ifm Electronic OF5032 Reflexlichttaster

Product characteristics

• Type of light: infrared light
• Housing: threaded type

Application

• Function principle: Diffuse reflection sensor

Electrical data

• Operating voltage [V]: 10...36 DC
• Current consumption [mA]: < 30
• Protection class: II
• Reverse polarity protection: yes
• Type of light: infrared light
• Wave length [nm]: 880

Outputs

• Electrical design: PNP
• Output function: light-on/dark-on mode; (programmable)
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 200
• Switching frequency DC [Hz]: 320
• Short-circuit protection: yes
• Type of short-circuit protection: pulsed
• Overload protection: yes

Detection zone

• Range [mm]: 1...200; (white paper 200 x 200 mm)
• Range adjustable: no
• Max. light spot diameter [mm]: 92
• Light spot dimensions refer to: at maximum range

Operating conditions

• Ambient temperature [°C]: -25...60
• Protection: IP 67

Tests / approvals

• EMC: EN 60947-5-2,
, EN 55011, class B
• MTTF [years]: 891

Mechanical data

• Weight [g]: 154.2
• Housing: threaded type
• Dimensions [mm]: M12 x 1 / L = 60
• Thread designation: M12 x 1
• Materials: stainless steel (1.4571/316Ti )
• Lens material: PMMA

Displays / operating elements

• Display: switching status, 1 x LED, yellow
, operation, 1 x LED, green

Accessories

• Items supplied: lock nuts: 2

Remarks

• Pack quantity: 1 pcs.

Electrical connection

• Connection: Cable: 6 m, PUR; 3 x 0.34 mm²
