ifm Electronic O5H700 Laser Reflexlichttaster

Product characteristics

• Type of light: red light
• Laser protection class: 1
• Housing: rectangular

Application

• Special feature: Background suppression
• Function principle: Diffuse reflection sensor

Electrical data

• Operating voltage [V]: 10...36 DC
• Current consumption [mA]: 15
• Protection class: II
• Reverse polarity protection: yes
• Type of light: red light
• Wave length [nm]: 655

Outputs

• Electrical design: PNP
• Output function: light-on/dark-on mode; (programmable)
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 200
• Switching frequency DC [Hz]: 1000
• Short-circuit protection: yes
• Type of short-circuit protection: pulsed
• Overload protection: yes

Detection zone

• Range [mm]: 20...200; (white paper 200 x 200 mm 90% remission)
• Range on white object (90 % remission) [mm]: 20...200
• Range on grey object (18 % remission) [mm]: 20...160
• Range on black object (6 % remission) [mm]: 20...80
• Range adjustable: yes
• Diameter of the smallest detectable object [mm]: 1.5
• Max. light spot diameter [mm]: 1.2
• Background suppression available: yes

Operating conditions

• Ambient temperature [°C]: -10...60
• Protection: IP 67

Tests / approvals

• EMC: EN 60947-5-2,
• Laser protection class: 1
• Notes on laser protection: Caution:, laser light
, laser class:, 1, , EN / IEC60825-1:2007, , EN / IEC60825-1:2014, , Complies with 21 CFR 1040 except for deviations pursuant to Laser Notice No. 50, dated June 2007.
• MTTF [years]: 454

Mechanical data

• Weight [g]: 68.5
• Housing: rectangular
• Dimensions [mm]: 56 x 18.2 x 46.8
• Materials: housing: PA; bezel: s
