ifm Electronic KF5013 Kapazitiver Sensor

Product characteristics

• Electrical design: NPN
• Output function: normally open
• Sensing range [mm]: 1...6
• Housing: threaded type
• Dimensions [mm]: M12 x 1 / L = 60

Application

• Media: dry bulk material; liquids

Electrical data

• Operating voltage [V]: 10...36 DC; ("supply class 2" to cULus)
• Current consumption [mA]: < 12
• Protection class: III
• Reverse polarity protection: yes

Outputs

• Electrical design: NPN
• Output function: normally open
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 100
• Switching frequency DC [Hz]: 50
• Short-circuit proof: yes
• Overload protection: yes

Detection zone

• Sensing range [mm]: 1...6
• Sensing range adjustable: yes
• Factory setting sensing range [mm]: 4
• Real sensing range Sr [mm]: 4 ± 10 %

Accuracy / deviations

• Correction factor: glass: 0.6 / water: 1 / ceramics: 0.5 / PVC: 0.4
• Hysteresis [% of Sr]: 1...15
• Switch point drift [% of Sr]: -20...20

Operating conditions

• Ambient temperature [°C]: -25...70
• Protection: IP 65
• Increased immunity: yes

Tests / approvals

• EMC: EN 60947-5-2,
• MTTF [years]: 1042

Mechanical data

• Weight [g]: 39.3
• Housing: threaded type
• Mounting: flush mountable
• Dimensions [mm]: M12 x 1 / L = 60
• Thread designation: M12 x 1
• Materials: housing: stainless steel (1.4404 / 316L); cover: PEEK

Displays / operating elements

• Display: switching status, 1 x LED, yellow

Accessories

• Items supplied: lock nuts: 2

Remarks

• Pack quantity: 1 pcs.

Electrical connection - plug

• Connection: Connector: 1 x M12; codi
