ifm Electronic IM5173, Induktiver Sensor

Product characteristics

• Electrical design: PNP/NPN; (parameterisable)
• Output function: normally open / normally closed; (selectable)
• Communication interface: IO-Link
• Housing: rectangular
• Dimensions [mm]: 40 x 40 x 54

Electrical data

• Operating voltage [V]: 10...30 DC
• Current consumption [mA]: < 20
• Protection class: III
• Reverse polarity protection: yes

Outputs

• Electrical design: PNP/NPN; (parameterisable)
• Output function: normally open / normally closed; (selectable)
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 100
• Switching frequency DC [Hz]: 100
• Short-circuit protection: yes
• Overload protection: yes

Detection zone

• Switch point IO-Link [mm]: 4.9...24.3; (parameterisable)
• Measuring range IO-Link [mm]: 2.6...26

Accuracy / deviations

• Correction factor: steel: 1 / stainless steel: 0.8 / brass: 0.4 / aluminium: 0.4 / copper: 0.3
• Hysteresis [% of Sr]: 3...15
• Linearity error of analogue output [%]: ± 2 %; (of the final value of the measuring range)
• Repeatability analogue output [%]: ± 1 %; (of the final value of the measuring range)
• Temperature coefficient: ± 0,2 %/K; (of the final value of the measuring range)

Interfaces

• Communication interface: IO-Link
• Transmission type: COM2 (38,4 kBaud)
• IO-Link revision: 1.1
• SDCI standard: IEC 61131-9 CDV
• Profiles: Smart Sensor: Device Identification; Device Diagnosis; Device Teach Channel; Binary Data Channel; Process Data Variable
• SIO mode: yes
• Required master port type: A
• Min. process cycle time [ms]: 3
• Supported DeviceIDs:
  • Type of operation, DeviceID: default, 791

  Operating conditions

  • Ambient temperature [
