ifm Electronic IE5456, Induktiver Sensor

Product characteristics

• Electrical design: PNP/NPN; (parameterisable)
• Output function: normally open / normally closed; (parameterisable)
• Communication interface: IO-Link
• Housing: threaded type
• Dimensions [mm]: M8 x 1 / L = 50

Application

• Special feature: Gold-plated contacts

Electrical data

• Operating voltage [V]: 10...30 DC
• Current consumption [mA]: < 15
• Protection class: III
• Reverse polarity protection: yes

Outputs

• Electrical design: PNP/NPN; (parameterisable)
• Output function: normally open / normally closed; (parameterisable)
• Max. voltage drop switching output DC [V]: 2.5
• Permanent current rating of switching output DC [mA]: 100
• Switching frequency DC [Hz]: 600
• Short-circuit protection: yes
• Overload protection: yes

Detection zone

• Switch point IO-Link [mm]: 1.13...5.61; (parameterisable)
• Measuring range IO-Link [mm]: 0.6...6

Accuracy / deviations

• Correction factor: steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.5 / copper: 0.4
• Hysteresis [% of Sr]: 3...15
• Note on hysteresis: parameterisable
• Linearity error IO-Link [%]: ± 3; (of the final value of the measuring range)
• Repeatability IO-Link [%]: ± 2; (of the final value of the measuring range)
• Temperature drift: ± 10 %; (of the final value of the measuring range)

Interfaces

• Communication interface: IO-Link
• Transmission type: COM2 (38,4 kBaud)
• IO-Link revision: 1.1
• SDCI standard: IEC 61131-9
• Profiles: Smart Sensor: Identification and diagnosis; Multi-channel, two setpoint switching sensor, type 0 Generic Profiled Sensor; Teach Channel
• SIO mode: yes
• Required master port type: A
• Min. process cycle time [ms]: 3.2
• IO-Link process data
