ifm Electronic GI701S Induktiver Sicherheitssensor

Product characteristics

• Electrical design: PNP
• Output function: 2 x OSSD (A1 and A2)
• Enable zone [mm]: 6...12
• Housing: threaded type
• Dimensions [mm]: M30 x 1.5 / L = 80

Application

• Special feature: Gold-plated contacts
• Type of operation: continuous operation (maintenance-free)
• Safety-related function: safe state when undamped
• Application: industrial application

Electrical data

• Operating voltage [V]: 19.2...30 DC
• Rated insulation voltage [V]: 30
• Current consumption [mA]: < 30
• Protection class: III
• Reverse polarity protection: yes
• Max. power-on delay time [ms]: 5000

Outputs

• Electrical design: PNP
• Output function: 2 x OSSD (A1 and A2)
• Max. voltage drop switching output DC [V]: 2.5; (100 mA)
• Permanent current rating of switching output DC [mA]: 100
• Output data: Interface type C class 0
• Output voltage at 24 V: compatible with EN 61131-2 inputs type 1, 2, 3
• Short-circuit protection: yes
• Max. capacitive load CL_max [nF]: 20

Detection zone

• Enable zone [mm]: 6...12
• Safe switching-off distance s(ar) [mm]: 30

Response times

• Response time to safety request [ms]: 50
• Response time when approaching the enable zone [ms]: 200
• Risk time (response time for safety-related faults) [ms]: 100

Operating conditions

• Applications: class C to EN 60654-1 weatherproof application
• Ambient temperature [°C]: -25...70
• Note on ambient temperature: operational life ≤ 87600 h
• Ambient temperature [°C]: 10...40
• Note on ambient temperature: operational life ≤ 175200 h
• Rate of temperature change [K/min]: 0.5
• Max. relative air humidity [%]: briefly: 5...95 %; permanent: 5...70 %
• Air pressure [kPa]: 80...106
• Max. height
