ifm Electronic EC2061 Neigungsschalter

Product characteristics

• Number of measurement axes: 1; (Z)
• Angular range [°]: 1…-6
• Housing: plastic housing

Application

• Function principle: static
• Operating principle: noble metal with liquid

Electrical data

• Operating voltage [V]: 8...30 DC
• Max. current consumption [mA]: 700
• Protection class: III
• Reverse polarity protection: yes
• Reverse polarity protection: yes

Inputs / outputs

• Number of inputs and outputs: Number of digital outputs: 1

Outputs

• Output signal: switching signal
• Number of digital outputs: 1
• Output function: normally open

Measuring/setting range

• Note on setpoint SP: switch point (ON): 0° = horizontal (absolute) installation position
, reset point (OFF): -2...-5° (counterclockwise movement of the cable outlet), hysteresis SP and RP: +/- 1°
• Number of measurement axes: 1; (Z)
• Angular range [°]: 1…-6

Accuracy / deviations

• Accuracy [°]: 0,2
• Repeatability [°]: <0,2

Operating conditions

• Ambient temperature [°C]: -30...80
• Storage temperature [°C]: -30...80
• Protection: IP 67

Tests / approvals

• MTTF [years]: 571

Mechanical data

• Weight [g]: 226.9
• Housing: plastic housing
• Type of mounting: Metallbuchse Ø 6,3 mm zur Befestigung des Neigungsschalters Loch Ø 4,5 mm zur Fixierung des Neigungsschalters
• Dimensions [mm]: 75 x 22 x 18
• Installation position: horizontal

Remarks

• Pack quantity: 1 pcs.

Electrical connection

• Connection: Cable: 3.1 m, PVC
