ifm Electronic E43366 T Stück

Application

• Pressure rating [bar]: 25
• Note on pressure rating: applies to the connection sensor/adapter
, higher pressure ranges on request

Tests / approvals

• Pressure Equipment Directive: A possible classification to PED depends on the application and has to be carried out by the user / operator.
• Safety instructions: The compatibility between medium and product material has to be checked in all applications.

Mechanical data

• Weight [g]: 282.9
• Materials: stainless steel (1.4435 / 316L)
• Sensor connection: G 1/2 sealing cone
• Process connection: welding adapter DN20; (Ø 23 mm x 1,5 mm)
• Surface characteristics Ra/Rz of the wetted parts: 0.8 / 4

Remarks

• Pack quantity: 1 pcs.

E43366-00 — 04.03.2024 —
