ifm Electronic E43201 Flanschplatte für Füllstandsensoren

Application

• Design: for level sensors LR
• Installation: according to DIN 24557
• Tank pressure [bar]: -1...16

Operating conditions

• Ambient temperature [°C]: 0...80

Mechanical data

• Weight [g]: 257.3
• Type of mounting: according to DIN 24557
• Materials: flange: stainless steel (1.4305 / 303); Sealing: NBR
• Tightening torque [Nm]: 6...9
• Sensor connection: threaded connection G 3/4 internal thread
• Process connection: flange Ø 90 mm

Remarks

• Pack quantity: 1 pcs.

E43201-00 — 14.11.2012 —
