ifm Electronic E30398 IO Link Memory Plug

Electrical data

• Operating voltage [V]: 18...32 DC
• Current consumption [mA]: < 35
• Min. insulation resistance [MΩ]: 100; (500 V DC)
• Protection class: III
• Reverse polarity protection: yes

Outputs

• Output signal: IO-Link
• Electrical design: PNP
• Max. voltage drop switching output DC [V]: 0.5
• Permanent current rating of switching output DC [mA]: 500; (briefly: 2 A / 50 ms)
• Type of short-circuit protection: depending on the connected sensor

Interfaces

• Communication interface: IO-Link
IO-Link Device
• Transmission type: COM2 (38,4 kBaud)
• IO-Link revision: 1.1
• Profiles: no profile
• SIO mode: no
• Required master port type: A
• Min. process cycle time [ms]: 2.5
IO-Link Master
• Transmission type: COM1 (4,8 kBaud); COM2 (38,4 kBaud)
• IO-Link revision: 1.1
• SDCI standard: IEC 61131-9 (Draft)
• Number of ports class A: 1

Operating conditions

• Ambient temperature [°C]: -25...60
• Storage temperature [°C]: -40...85
• Protection: IP 65; IP 67

Tests / approvals

• EMC: EN 61000-6-2,
• Shock resistance: DIN IEC 68-2-27, 50 g 11 ms
• Vibration resistance: DIN IEC 68-2-6, 20 g (10...2000 Hz)
• MTTF [years]: 655.69

Mechanical data

• Weight [g]: 116.5
• Dimensions [mm]: M12 x 1
• Thread designation: M12 x 1
• Materials: PA PACM 12 (TROGAMID); PET
• Sealing material: FKM

Displays / operating elements

• Display: operation, 2 x LED, green

Remarks

• Remarks: only for positive switching sensors
, The memory plug acts as master if it is connected with a sensor., The memory plug acts as device if it is used with the service program., operating voltage "supply class 2" according to cULus
• Pack quantity: 1 pc
