ifm Electronic E11847 Zentralverteiler

Electrical data

• Operating voltage [V]: 10...36 DC
• Protection class: III
• Max. current load per module/slot [A]: 4
• Max. current load total [A]: 6

Outputs

• Electrical design: PNP

Operating conditions

• Ambient temperature [°C]: -5...70
• Protection: IP 69K; (To ensure the protection rating unused sockets must be covered with the supplied protective caps.; Tightening torque: 1,3 Nm +/- 0,1 Nm)

Tests / approvals

• MTTF [years]: 2487

Mechanical data

• Weight [g]: 5376
• Dimensions [mm]: Ø 137.3 / L = 72
• Materials: threaded bush: stainless steel (1.4404 / 316L); LED-Fenster: PC; O-ring: EPDM; Protective cap: PP
• Moulded-body material: stainless steel
• Number of ports splitter box : 8
• Connector type: M12

Displays / operating elements

• Display: switching status, 16 x LED, yellow
, operation, 1 x LED, green

Accessories

• Items supplied: Protective caps: M12

Remarks

• Remarks: external voltage supply according to PELV
• Pack quantity: 1 pcs.

Electrical connection

• : Cable: 25 m, PUR / PVC, black, Ø 11 mm; 3 x 0.75 mm² + 16 x 0.34 mm²

Electrical connection - slot

• Connection: Connector: 8 x M12; coding: A; Moulded body: stainless steel

E11847-00 — 12.09.2022 —
