ifm Electronic AC2616 AS Interface Universalmodul

Application

• Application: field installation

Electrical data

• Operating voltage [V]: 26.5...31.6 DC
• Max. current consumption from AS-i [mA]: 140
• Reverse polarity protection: yes
• Additional voltage supply [V]: 24...30 DC; (AUX)
• Additional voltage supply: optional
• Max. current consumption from additional supply [mA]: 550; (AUX)

Inputs / outputs

• Number of inputs and outputs: Number of analogue inputs: 2

Inputs

• Sensor supply of the inputs: AS-i / AUX
• Max. total current rating of inputs [mA]: 100
• Number of analogue inputs: 2; (Anschluss von 2-, 3-, 4-Draht-Sensoren)
• Analogue input (current) [mA]: 4...20
• Analogue inputs protected against short circuits: no
• Resolution of analogue input: 16 (1 bit = 1 µA)
• Precision analogue input [%]: 0,5

Operating conditions

• Ambient temperature [°C]: 0...70
• Storage temperature [°C]: -25...85
• Max. relative air humidity [%]: 90; (non condensing)
• Max. height above sea level [m]: 2000
• Protection: IP 65

Tests / approvals

• EMC: EN 50295,
• MTTF [years]: 150

AS-i classification

• AS-i master profile: M3; M4
• AS-i profile: S-7.3.D
• AS-i I/O configuration [hex]: 7
• AS-i ID code [hex]: 3.D
• Assignment of the parameter bits:
  , parameter bit, Designation, , , , , , P0, filter in the A/D converter, : 1, 50 Hz, * / 0, 60 Hz, , P1, channel, 2: 1, projected, / 0, not projected, , P2, peripheral fault, : 1, activated, / 0, deactivated, , P3, not used, : 1, reserved, / 0, not reserved,

  Mechanical data

  • Weight [g]: 287
  • Type of mounting: AS-i interface to FC-E lower parts
  • Materials: PBT
