ifm Electronic EY3090 Verbindungskabel zum Anschluss von Sicherheitslichtvorhängen

Application

• Special feature: Free from silicone; Halogen-free; Gold-plated contacts
• Design: For the connection of safety light curtains / safety light grids with OSSD, for receivers
• Application: configured for automatic operation
• Free from silicone: yes

Electrical data

• Operating voltage [V]: < 36 DC
• Protection class: II
• Max. current load total [A]: 4; (...40 °C)

Operating conditions

• Protection: IP 67

Mechanical data

• Weight [g]: 47
• Materials: TPU orange; PA
• Moulded-body material: TPU / PA
• Material nut: brass, nickel-plated

Remarks

• Pack quantity: 1 pcs.

Electrical connection

• : Cable: 0.1 m, PUR, Halogen-free, black, Ø 4.9 mm; 5 x 0.34 mm² (42 x Ø 0.1 mm )

Electrical connection - plug

• Connection: Connector: 1 x M12, straight; coding: A; Moulded body: TPU / PA, orange; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...0.7 Nm

Electrical connection - socket

• : Connector: 1 x M12, straight; coding: A; Moulded body: TPU / PA, orange; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm

EY3090-00 — 25.06.2009 —
