Telco SMT 8000 PG J, Fotovoltaikanlage, P/n: 6166
Technische Daten
- Gewicht
- 1 kg
Produktbeschreibung
- Operation Mode: Thru Beam
- Function: Transmitter
- Supply Voltage: 10 - 30 V dc
- Light Source: Infrared (880 nm)
- Control Feature: Test input
- Sensing Range: 20 m
- Housing: M18 x 1
- Housing Material: Plastic
- Connection: 4 pin, M12 plug
- Supply Voltage: 10 - 30 V dc
- Voltage Ripple: 15 %
- Reverse Polarity Protected: Yes
- Current Consumption: 15 mA
- Test Input: Yes
- Power On Indicator: Green LED
- Light Source: Infrared (880 nm)
- Emission Angle: +/- 2°
- Housing Material, Front Lens: Polycarbonate
- Housing Material, Sensor Housing: Polycarbonate
- Vibration: 10 - 55 Hz, 0,5 mm
- Shock: 30 g
- Operation Temperature: -20 to +60 °C
- Storage Temperature: -40 to +80 °C
- Sealing Class: IP 67
