Telco SMT 6000 SG 5, Fotovoltaikanlage, P/n: 7737
Technische Daten
- Gewicht
- 1 kg
Produktbeschreibung
- Operation Mode: Thru Beam
- Function: Transmitter
- Supply Voltage: 10 - 32 V dc
- Light Source: Infrared (880 nm)
- Control Feature: Adjustable range and test input
- Sensing Range: 6 m
- Housing: 9,5 x 11,5
- Housing Material: Plastic
- Connection: 5 m cable
- Supply Voltage: 10 - 32 V dc
- Voltage Ripple: 15 %
- Reverse Polarity Protected: Yes
- Current Consumption: Max. 320 mW
- Test Input: Yes
- Control Input: Adjustable range
- Light Source: Infrared (880 nm)
- Emission Angle: +/- 10°
- Housing Material, Front Lens: Polycarbonate
- Housing Material, Sensor Housing: Polyester
- Cable: 3 x 0,14 mm²
- Cable Sleeve: PVC ø 4,0 mm
- Vibration: 10 - 55 Hz, 0.5 mm
- Shock: 30 g
- Operation Temperature: -20 to +60 °C
- Storage Temperature: -40 to +80 °C
- Sealing Class: IP 67
